Log on with user name and password (default: admin, password: admin).
5.1.3 Starting the Command Line Interface over the serial connection
If you do not know the IP address of the device, you can use the command
line interface via a serial connection.
Use the serial configuration cable to connect the LANCOM switch to the
configuration computer (see "Mounting and connecting up the LANCOM
Switch').
Start a terminal program on the configuration computer, such as PuTTY.
Use the following parameters for the connection:
Baud rate: 115200
Stop bits: 1
Data bits: 8
Parity: N
Flow control: none
Log on with user name and password (default: admin, password: admin).
5.2 Monitoring the LANCOM switch with LANmonitor
The current state of the device and all ports can be monitored using the LEDs
on the front panel. With LANmonitor the devices can be observed from any
workstation without being able to see the LEDs. Besides the status informa-
tion provided by the LEDs the LANmonitor provides further important infor-
mation on the ports.
5.2.1 Ethernet port status
LANmonitor displays the current status of all of the device's Ethernet ports.
This includes monitoring of the state as configured by the admin (config state)
and the actual state (link state) of the port. Each port is displayed with two
colored symbols in LANmonitor:
The left icon shows the config state:
Gray: The port is deactivated in the configuration
Yellow: The port is activated in the configuration
The right-hand icon shows the link state:
Gray: No active network device is connected to the port
Installation Guide LANCOM GS-2310P/GS-2326(P+)/GS-2352(P)
Chapter 5: Configuring and monitoring the LANCOM switch
25
