Langwiesen 7
A-4209 Engerwitzdorf
T: +43-7235-605-0
F: +43-7235-605-8
info@epluse.com
www.epluse.com
MANUAL EE10 SERIES
TRANSMITTER FOR HUMIDITY / TEMPERATURE
GENERAL:
EE10 transmitter series are designed for accurate measurement of humidity and temperature.
The stylish, functional housing for wall mounting makes easy installation and fast exchange of the sensing
unit for service purposes possible.
Main application for the EE10 is climate control in residential and office areas, switching cabines, hotels
and museums, etc.
Absolutely avoid extreme mechanical and unspecified strain!
TECHNICAL DATA:
Measuring Quantities
Relative Humidity
Humidity sensor
Analogue output 0...100 % RH
Working range
1)
Accuracy at 20°C
and U
=24VDC
(68°F)
V
Temperature influence at 60% RH
Temperature (active output)
Analogue output 0...50°C
2)
(32...122°F)
Accuracy at 20°C
and U
=24VDC
(68°F)
V
Temperature (passive output)
Type of T-Sensor
General Data
Voltage supply (U
)
V
for 0 - 10 V
for 4 - 20 mA
Current consumption
Electrical connection
Display for EE10-FTx version
for EE10-Fx and EE10-FPx version humidity
CE compatibility according
Temperature ranges
1) Please refer to the working range of the HC103
2) Other T-scaling on request
technical data are subject to change
Austria
HC103
0-10 V
-1 mA < I
< 1mA
L
4-20 mA (two wires)
R
< (U
-10)/0.02 < 500 Ohm
L
V
0...95 % RH
±2% RH (40...60% RH)
±3% RH (10...90% RH)
typical 0.06% RH /°C (0.03% RH / °F)
0-10 V
-1 mA < I
< 1mA
L
4-20 mA (two wires)
R
< (U
-10)/0.02 < 500 Ohm
L
V
FT3: ±0.25°C
FT6: ±0.4°C
(±0.45°F)
please see ordering guide
15 - 40 VDC or 24 VAC ±20%
28V DC > U
> 10 + 0.02 x R
(R
< 500 Ohm)
V
L
L
for DC supply:
typical 4 mA
for AC supply:
typical 15 mA
eff
screw terminals max. 1.5 mm
2
(AWG 16)
humidity / temperature alternating
EN 50081-1
FCC Part15 ClassB
EN 50082-1
ICES-003 ClassB
working temperature range:
-5...55°C
working temperature with display:
-5...55°C
storage temperature range:
-25...60°C
Opening the housing:
Press pin A until cover can be opened.
Closing the housing:
Set cover into flute B and move it to direction C until pin A snaps in.
Installation:
Mount housing on wall with srews through therefore designated
holes D.
MOUNTING HOLES:
CONNECTION DIAGRAMS:
(±0.72°F)
EE10-FT3
EE10-FT6
(23...131°F)
(23...131°F)
(-13...140°F)
A
D
C
dimensions: 85x100x26mm (WxHxD)
EE10-F3
EE10-FP3
EE10-F6
EE10-FP6
B
