• Do not exert lateral pressure on the grinding or cut-off
wheel.
• Do not cut a workpiece of a thickness larger than the
maximum cutting depth of the cut-off wheel.
• When quick release flange is used, make sure that inner
flange seated on the spindle is equipped with rubber O-ring
and this ring is not damaged. Also surfaces of the outer
flange and the inner flange must be clean.
• Use quick release flange only with cutting and grinding
discs. Use only flanges that are free from defects, that
operate correctly.
• In case of temporary mains power failure or after
disconnecting plug from mains socket with the switch in ON
position, unlock the switch and set it to OFF position before
starting the tool again.
NOTE: The tools is intended for indoor works.
Despite using the construction, which is safe by design itself,
protection means and additional safety features, there is
always a residual risk of injuries during operation.
Descriptions of used pictograms.
1 2 3
5 6 7
Warning, take special precautions.
1.
Read the instruction manual, observe warnings and safety
2.
conditions included in it!
Use personal protection equipment (safety goggles, ear
3.
protectors).
Use safety gloves.
4.
Disconnect the power cord, before maintenance or repair
5.
works are begun.
Keep out of reach of children.
6.
Protect against rain
7.
Protection class II
8.
DESIGN AND APPLICATION
The angle grinder is a hand-held power tool with the II
class isolation. The power tool is driven with a single-phase,
commutator motor, whose rotational speed is reduced by means
of an intersecting axis gear. The power tool can used both for
grinding and cutting. This type of power tools is widely used for
removal of burrs from metal surfaces, weld surface processing,
cutting light-wall tubes and other small metal objects etc. They
are used in engineering industry, automotive and chemical
industry. With the use of proper tools, the angle grinder can be
used not only for cutting or grinding, but also for rust and paint
coats removal.
The areas of its application include repair and construction
works, not only related to metals. The angle grinder can also be
used for cutting and grinding of construction materials, such as
brick, paving stones, ceramic tiles, etc.
The power tool is designed for dry operation only and it must
not be used for polishing. The power tool should be used
according to its purpose.
Use inconsistent with its purpose
• Do not work materials that contain asbestos. Asbestos is
• Do not work materials, whose dust is inflammable or
• Do not use cut-off wheels for grinding. The cut-off wheels
DESCRIPTION OF GRAPHIC PAGES
The below list refers to device components shown in the graphic
pages of this instruction manual.
1.
2.
3.
4 4.
5.
6.
8.
8
10.
* There can be differences between the drawing and actual product.
DESCRIPTION OF USED GRAPHIC SIGNS
EQUIPMENT AND ACCESSORIES
1.
2.
3.
ATTACHING THE ADDITIONAL HANDLE
The additional handle (3) is installed in one of the holes in the
grinder head. It is recommended to use the grinder with the
additional handle. When holding the grinder with both hands
(also using the additional handle), there is less risk of touching
the grinder wheel or brush with your hand, as well as of injuries
during recoil.
15
carcinogenic.
explosive. During operation, the power tool produces sparks,
which may ignite emitted vapours.
are used to cut with its face, while grinding with lateral surface
of such a cut-off wheel threatens with its damages and puts the
operate in danger of injuries.
Spindle lock button
Switch
Additional handle
Grinding wheel cover
External flange
Internal flange
Speed control dial
Lever (grinding disc guard)
NOTE
WARNING
FITTING/SETTING
INFORMATION
Grinding wheel guard
Socket spanner
Additional handle
PREPARATION FOR WORK
- 1 pce
- 1 pce
- 1 pce
