steel mount plate 6mm thick is recommended. Fasteners should be steel high tensile grade 5 or
better. A poorly designed mount may void warranty.
7. The winch should be secured to the mounting with 3/8" UNC x 1-1/4" stainless steel bolts and
spring washers provided.
8. The roller fairlead is to be mo.unted so as to guide the rope onto the drum evenly.
5.2 Lubrication installation
All moving 'Parts in the winch are permanently lubricated with high temperature lithium grease
at the time of assembly. Under normal conditions factory lubrication will surfice. Lubricate cable
periodically using light penetrating oil. Inspect for broken strands and replace if neccessary. If the
cable becomes worn or damaged it must be replaced.
5.3

Cable installation

Unwind the new cable by rolling it along the ground, to prevent kinking. Remove old cable and
obsevre the manner in which it is attached to the cable drum flange.
6. Electrical connection
For normal self-recovery work, your existing electrical system is adequate. A fully charged battery
and proper connections are essential. Run the vehicle engine during winching operations to keep
battery charged.
Pay close attention to proper electrical cable connection as follows (refer to following Diagram)
1. Short red cable (8) connecting to the red terminal (B) of the motor.
2. Short black cable with yellow jacket (9) connecting to the yellow terminal (D) of the motor.
3. Short black cable with black jacket (10) connecting to the black terminal (C) of the motor.
4. Thin black cable (11) connecting to bottom terminal (A) of the motor.
5. Long black cable (1.8m), one terminal (12) connecting to the bottom terminal (A) of the motor,
and the other terminal negative (-) connecting to negative (-) terminal of battery.
6. Long red cable (13) positive (+) connecting to positive (+) terminal of battery.
