Characteristics Of The Outputs - IFM Electronic ecomot100 SafetyController R 360 Montage- Und Installationshinweise

CR7505
Outputs (B , PWM, PWM )
H I
-- %QX0.00...03
%QX0.04...07
can be configured as ...
Overload protection
(valid for all outputs)
Internal relay outputs
for the additional deactivation
of the outputs
Output Error
Abbreviations
= safety-related
-- = not safety-related
A = analogue
B = binary High Side
H
B = binary Low Side
L
FRQ/CYL = frequency inputs
I = pulse High Side
H
I = pulse Low Side
L
PWM = pulse width modulation
PWM = current-controlled output
I
%IW... = IEC address for analogue input
%IX... = IEC address for binary input
%QX... = IEC address for binary output
ifm electronic gmbh • Teichstraße 4 • 45 127 Essen
All manuals and user guides at all-guides.com
Semiconductor outputs, with diagnostic capability
positive switching (high side), short-circuit and overload protected
switching voltage 10...32 V DC
switching current max. 4 A
output frequency max. 100 Hz (depending on the load)
PWM outputs, diagnosis via current feedback
PWM frequency max. 250 Hz
mark-to-space ratio 1...99 %
resolution depends on the PWM frequency
load current max. 4 A
Current-controlled outputs, diagnosis via current feedback
load current 0,1...4 A
min. 3 Ω (at U
load resistance
min. 6 Ω (at U
setting resolution 1 mA
control resolution 5 mA
accuracy ± 2% FS
max. 5 minutes (at 100%)
Normally open contacts in series to 2 groups of 4 semiconductor outputs.
Sustained forcing by means of hardware and additional controlling
by means of user program.
The relays must always be switched without load!
total current max. 12 A per group
switching current 0.1...15 A
overload current 20 A
≥ 10
number of operating cycles
≤ 3 ms
switching-time constant
Semiconductor output, positive switching (high side)
switching voltage 10...32 V DC
switching current max. 100 mA
overload current 0.5 A
switching function OFF (0 V) in case of an error
wiring see page 5
We reserve the right to make technical alterations without prior notice.
S
AFETY

Characteristics of the outputs

= 12 V DC)
B
= 24 V DC)
B
6
(without load)
C CR7505
ONTROLLER
CR7505 / page 4 16.10.2006
31
PAGE
