External connectors rear
USB 2.0
USB 2.0
1
2
USB 3.0
19
1
6 = USB3_TX positive (P2)
7 = GND
FAN 1 = Heatsink CPU
FAN 2 = Front Fan HDD/CPU
FAN 3 = Front Fan Slotcards
Fujitsu
Mouse
KeyB
USB 2.0
Power Supply
Temp. Sensor
USB 3.0
LAN
USB 2.0
Audio
Intel-LAN
PCIe1
PCIe1
PCI
Audio
PCI
Audio Frontpanel
DVI-I USB 3.0 USB 2.0
5V USB
1 =
2 = 5V USB
3 = Data negative Port X
4 = Data negative Port Y
5 = Data positive Port X
1 = 5V USB
2 = USB3_RX negative (P2)
3 = USB3_RX positive (P2)
4 = GND
5 = USB3_TX negative (P2)
Channel B, Slot 2
Channel B, Slot 4
Channel A, Slot 1
Channel A, Slot 3
CPU LGA1155
PCIe4(16)
PCIe16
Temp. Sensor
PCH
Desc Override Enable
PCIe1(16)
6 = Data positive Port Y
7 = GND
8 = GND
9 = Key
10 = Not connected
8 = Data negative (P2)
9 = Data positive (P2)
10 = FP Detect
11 = Data positive (P3)
12 = Data negative (P3)
13 = GND
14 = USB3_TX positive (P3)
Internal connectors and slots
Battery
Temp. Sensor HDD/ODD
Power
GFX Power
Switch
SCSI-LED
FAN1
USB 3.0
1/2 Front
Intrusion
TPM Enable
Super
I/O
FAN2
SATA 2 SATA 4 SATA 0
SATA 3 SATA 5 SATA 1
USB 1/2 USB 3/4
INT Front
USB 1 INT
FAN3
Front panel
Reset
Recovery Power
On/Off
Recovery inserted = The system starts
from USB stick and allows a BIOS recovery.
Details can be found in the BIOS manual.
15 = USB3_TX negative (P3)
16 = GND
17 = USB3_RX positive (P3)
18 = USB3_RX negative (P3)
19 = 5V USB
20 = Not connected
A26361-D3167-Z320-1-7419
HD-LED
1
2
Power LED
