< 50 lbs. (22.7 kg)
A
1x
1
2
M4 x 25mm
6x
3
1x
4
1/8"
Stud Finder
Localizador de largueros de madera
Stud Finder
Auswahl von Montagematerial
Positiebepaler balken
Rilevatore di montanti
螺栓探测器
스터드 파인더
888-45-198-W-00 rev.A • 03/11
All manuals and user guides at all-guides.com
B
C
1x
1x
8x
12mm
M4 x 6mm
2.5mm
Ø 3/8" (10 mm)
Concrete
Concreto
Béton
Massivbeton
Beton
Cemento
水泥质
콘크리트
LX HD Wall Mount Pivot
± 20˚
D
4x
2x
M8 x 80mm
6x
4x
M4 x 12mm
4x
10-24 x 5/8"
Ø 3/16" (5 mm)
Wood
Madera
Bois
Solide Holzbalkenträger
Massief Houten Pilaren
Due montanti in legno massiccio
木质
나무
ASSEMBLY INSTRUCTIONS
INSTRUCCIONES DE INSTALACIÓN
NOTICE D'ASSEMBLAGE
MONTAGEANLEITUNGEN
INSTALLATIE INSTRUCTIES
MANUALI D'ISTRUZIONE
- 5˚
+ 15˚
E
F
6x
M4 x 14mm
2x
6x
6mm
M6 x 14mm
1x
安装说明
설치 안내
M4 x 8mm
13mm
1 of 10
Verwandte Anleitungen für Ergotron LX
Inhaltszusammenfassung für Ergotron LX
- Seite 1 All manuals and user guides at all-guides.com LX HD Wall Mount Pivot ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE INSTALACIÓN NOTICE D’ASSEMBLAGE MONTAGEANLEITUNGEN INSTALLATIE INSTRUCTIES MANUALI D’ISTRUZIONE 安装说明 설치 안내 - 5˚ ± 20˚ + 15˚ < 50 lbs. (22.7 kg) M4 x 14mm...
- Seite 2 All manuals and user guides at all-guides.com WALL PLATE MOUNTING INSTRUCTIONS 1.125" (28.6mm) INSTRUCCIONES DE MONTAJE DE LA PACADA DE PARED INSTRUCITONS POUR LE MONTAGE DE LA PLATINE MURALE WANDHALTERUNG BEFESTIGUNGSHINWEISE 6" WANDPLAAT BEVESTIGINGSINSTRUCTIES (152mm) ISTRUZIONI PER IL MONTAGGIO DELLA PIASTRA A MURO 4.1"...
- Seite 3 All manuals and user guides at all-guides.com WOOD CONCRETE ERGOTRON PRODUCT MADERA CONCRETO PRODUCTO ERGOTRON BOIS BÉTON PRODUIT ERGOTRON HOLZBALKENTRÄGER MASSIVBETON ERGOTRON PRODUKT MASSIEF HOUTEN PILAREN BETON ERGOTRON-PRODUCT DUE MONTANTI IN LEGNO MASSICCIO CEMENTO PRODOTTO ERGOTRON ERGOTRON 产品 木质 水泥质...
- Seite 4 All manuals and user guides at all-guides.com WOOD MADERA BOIS HOLZBALKENTRÄGER MASSIEF HOUTEN PILAREN DUE MONTANTI IN LEGNO MASSICCIO 木质 나무 Ø 3/16" (5 mm) CAUTION: Make sure the wall mount bracket is level, fl ush and snug to the wall surface. DO NOT OVERTIGHTEN THE BOLTS.
- Seite 5 All manuals and user guides at all-guides.com CONCRETE WARNING: CONCRETO Mounting holes must be at least 3-1/8” (80mm) deep and must be located within solid con- BÉTON crete, not mortar or covering material. If you drill into an area of concrete that is not solid, MASSIVBETON reposition mounting holes until both anchors can be fully inserted into solid concrete! BETON...
- Seite 6 All manuals and user guides at all-guides.com CONCRETE CONCRETO WARNING: BÉTON Anchors that are not fully set in solid MASSIVBETON concrete will not support the applied BETON load resulting in an unstable, unsafe condition which could lead to per- CEMENTO sonal injury and/or property damage.
- Seite 7 All manuals and user guides at all-guides.com To Stop Portrait/Landscape Rotation insert Screw M4 x 8mm 360° 0° ATTACH DISPLAY ATORNILLE MONITOR FIXER L’ECRAN MONTAGE DES DISPLAYS BEVESTIG BEELDSCHERM FISSARE IL DISPLAY 安装显示器 디스플레이 부착 75 x 75mm 100 x 100mm 200 x 100mm 200 x 200mm 75 x 75mm...
- Seite 8 All manuals and user guides at all-guides.com 200 x 100mm M4 x 14mm M4 x 6mm 200 x 200mm M4 x 6mm M4 x 6mm M6 x 14mm 888-45-198-W-00 rev.A • 03/11 8 of 10...
- Seite 9 All manuals and user guides at all-guides.com 75 x 75mm 100 x 100mm 12mm 200 x 100mm M4 x 25mm ATTACH TO WALL MOUNT BRACKET ATORNILLAR AL SOPORTE PARA MONTAJE EN PARED INSTALLER SUR LA FIXATION MURALE MONTAGE AN WANDMONTAGEPLATTE BEVESTIG AAN WANDHOUDER FISSARE ALLA STAFFA DI FISSAGGIO A MURO 安装至壁式安装支架...
- Seite 10 All manuals and user guides at all-guides.com Adjust Pan – Side-to-side: If it does not stay in place or movement is stiff , tension needs adjustment. Adjust until motion is equal. Ajuste Giro (derecha e izquierda): Si el movimiento es excesivo o demasiado rígido, se necesita aju- star la tensión.
