left and right swivel assembling controller on the handle pipe and rotate it inwards. To assembly the undercarriage
to the marginal position, press with your forearm on the handle (until you feel a slight resistance from undercarriage
chassis). Ensure with transport safety-catch. Assembled undercarriage can be braked off with your hand, if needed.
Do not rest folded stroller by the extensible locks on handle pipes, the folding function could be damaged.
Wheels
Mounting - press the quick fastening mechanism of the wheel, put the wheel on the axis and release the mechanism.
By pulling the wheel make sure, that the wheel is mounted correctly and cannot get loose.
Releasing - press the quick fastening mechanism of the wheel and remove it form the axis.
Parking brake
To apply the parking brake, press the plastic brake pedal. Please check the brakes regularly and keep good function-
ality by cleaning and greasing of the mechanism by silicone grease. ( plastic slider inside has to be loosely movable)
Height of the handle
The height of the handle can be set by pressing the black plastic articulations of the handle on both sides simultane-
ously and setting it to the desired position.
Stroller operation:
Changing the position of the seat:
The seat can be positioned in or against the direction of travel. Apply the breake on the stroller (stroller brake), take
the child out off the seat. Grasp the seat firmly, simultaneously press both buttons on the outside of the adapter
harness . Pulling upwards remove the seat from the chassis and turn in/against the driving direction. Place onto the
"clip- and -go" interface from above , put on adapters on each side of the lock . Ensure proper placement with sig-
nals of audible click. Pulling the seat up , make sure it is correctly locked ( can not be ejected ) .
Positioning of the seat:
You can set four position of the backrest . When installing the backrest unlock mechanism positioning the backrest
upwards , adjust it to the desired position and release mechanism with pressure on the backrest downwards you can
make sure that the backrest is fixed properly (is not possible to change its position). When you lift the backrest,
positioning is working automatically.
Safety Bar:
To fit the safety bar put both ends of safety bar in seat side tubes at once (pic.2). To take out the safety bar is en-
sured by the spring locking on both sides., press press-pin release and lift the safety bar up.
Footrest height adjustment:
Hold the footrest. Loose the footrest height adjusting bolts. Set the position of footrest and tighten properly both
adjusting bolts. Turn adjusting bolts small handles into the safest position by pulling it and rotating.
Footrest set reclining:
Press both press buttons (pic.1) on footrest hinge simultaneously and adjust the angle position of footrest. Free both
buttons and set the position of footrest to allow the hinges to be locked.
Getting over the curbs and low obstacles:
Down – hold the handlebar tightly; push the stroller upright with the front wheels to edge of the curb, press a little
handlebar down to lift a bit front wheels and then carefully ride off the curb on the rear wheels.
Up - push the stroller upright to the curb, press a little handlebar down to lift front wheels to desired height and ride
on to the walkway. Hold the handlebar tightly to keep stroller's side stability. Pull the handlebar a little up to lift the
rear wheels to desired height and ride on to the walkway. In any case do not bump with the front wheels to the curb!
Carrying stroller:
Use ramps and lifts if possible. If you have to get over the stairs or other obstacles, the stroller must be carried by 2
persons at least. Never do that if you or your assistant are not sure that you can carry the stroller with child safely.
During the carriage child must not have the hands out of stroller.
WARNINGS!! NEVER lift the stroller up by holding the grab bar, foot-rest, seat unit, carrycot or hood of the seat/
carrycot!!
Down from the stairs:
Hold the handlebar tightly; push the stroller upright with the front wheels to the top edge of the stairs. Your assis-
tant grabs the chassis above the front wheels. Both of you lift up the stroller, carefully carry that down and set back
again on all wheels.
Up to the stairs:
Hold the handlebar tightly; bring upright the stroller backing up to the lower step of the stairs. Your assistant grabs
the chassis above the front wheels. Both of you lift up the stroller and carry upstairs so you are going first and your
assistant second. Set the stroller back on all wheels in safe distance behind top edge of stairs.
MAINTENANCE, PRODUCT DISPOSAL:
The stroller has been designed to the high standard and with correct usage and maintenance will provide many years
of trouble free service.
