Operating and display elements

actual configuration not the
same as preset configuration
automatic addressing not
AS-i voltage ok
normal operation
LED is lit: projecting mode,
all slaves activated
LED flashing:slave 0 identified,
switching into protected
mode not possible
controller in run mode
only AC 1014
18
PAGE
released
ASI- DeviceNet- CONTROLLER
ifm electronic gmbh·D 45127 Essen
Made in Germany
PC
ALARM
CONFIG
NOT AUTO
ADDR
MODE SET
ASI
PWR
COM
MODE
PROJ
MODE
CTRL
ASI 2 +
ASI 2 –
+ 24 V
0 V
ASI 1 +
ASI 1 –
PE
Module/
Network
Status
2
R
S
2
3
3
2
5
C
4
set mode /
parameter
acknowledge
mode / parameter
slave no.
master 1 or 2
modes 1 to d
error messages
status LED
D
pin connection
E
V
1 screen,
I
1
C
not insulated
E
2 V+ (red)
N
E
3 V- (black)
T
4 CAN_H (white)
5 CAN_L (blue)
