Technical data
Print resolution
Print speed
Continuous mode
Intermittent mode
Back speed
Print width
Max. print length
Continuous mode
Intermittent mode
Frame passage width
Printhead
Acoustic emission (measuring distance 1 m)
Average sound pressure level
Transfer ribbon
Ink
Max. roll diameter
Core diameter
Max. length
Max. width
Dimensions (width x height x depth)
Print mechanics
without mounting frame
with mounting frame
Control unit
Weight
Print mechanics
Electronics with cable
Electronics
Processor
RAM
Slot
Battery Battery cache
Warning signal
Interfaces
Serial
Parallel
Ethernet
USB
Connection values
Pneumatic connection
Nominal voltage
Nominal current
Fuse values
Operation data
Temperature
Humidity
All manuals and user guides at all-guides.com
Dynacode 53
300 dpi
50 ... 800 mm/s
50 ... 600 mm/s
intermittent mode only: max. 600 mm/s
53,3 mm
6000 mm
75 mm
customized
Corner Type
60 dB(A)
outside or inside (option)
98 mm
25.4 mm / 1"
900 m
55 mm
204 x 180 x 234 mm
depending on passage width
240 x 125 x 332 mm
connecting cable set to mechanics 2.5 m
9.5 kg
5.5 kg
High Speed 32 Bit
16 MB / 64 MB (on demand)
Compact Flash card type I
for Real-Time clock (storage of data with shut-down)
accoustic signal when error
RS-232C (up to 115.200 Baud)
Centronics
10/100 Base T
1.1
min. 6 bar dry and free from oil
110 ... 230 V / 50 ... 60 Hz
230 V / 1,5 A − 110 V / 3 A
230 V / 2 AT − 110 V / 4 AT
5 ... 40 °C
max. 80% (non-condensing)
English
Dynacode 107
Dynacode 128
300 dpi
300 dpi
50 ... 600 mm/s
50 ... 450 mm/s
50 ... 600 mm/s
50 ... 600 mm/s
106,6 mm
128 mm
3000 mm
3000 mm
75 mm
75 mm
customized
customized
Corner Type
Corner Type
65 dB(A)
68 dB(A)
outside or inside (option)
outside or inside (option)
82 mm
75 mm
25.4 mm / 1"
25.4 mm / 1"
600 m
450 m
110 mm
130 mm
204 x 180 x 290 mm
204 x 180 x 312 mm
11 kg
11.7 kg
5.5 kg
5.5 kg
Dynacode
113
