Installation and operating instructions

Tools and recommended accessories for installation

- Scissors

- Pointed-nose pliers

- Cross-point screwdriver, size PH2, Order No. 5779.2

- Allen keys, 1.5, 2, 2.5 mm

- High-performance lubricating grease, Order No. 570

- High-performance oil, Order No. 206

- Thread-lock fluid Order No. 952

pliers

Assembly stage 1 (unpacking the model)

Carefully remove the boat from the packaging: cautiously cut the retaining bands with a pair of scissors, then

carefully lift the model out of the packaging and remove all the foam packing pieces.

Assembly stage 2 (fitting the propeller)

The propeller has an internal M4 thread, and is simply screwed onto the propeller shaft: locate the nut at

the end of the shaft and grip it tightly using a small pair of pliers. Now screw the propeller onto the threaded

shank. Apply a drop of UHU thread-lock fluid, Order No. 952, to secure the propeller on the shaft.

Installation Step 3 (Check the screw)

Check that the screws in the shaft coupling, the motor retaining clamp and the propeller are tight, as they

may have worked loose in transit. You can check this by pulling on the propeller: if the shaft slips aft when

you pull, one of the grubscrews is loose; carefully re-tighten it. IMPORTANT: if the grubscrews have come

loose, apply a drop of UHU thread-lock fluid (Order No. 952) to them, as vibration could cause them to work

loose again when the boat is running. Hold the shaft firmly in flat-nose pliers to prevent it slipping while you

tighten the grubscrews using an allen key.
