Mount the instrument
Damage to internal components can occur if a screw goes into the side of the refrigerated sampler more than
12.5 mm (0.5 in.). Use the screws supplied to prevent damage to the refrigerated sampler.
Attach the I/O module to a flat, vertical surface that lets the user easily disconnect the I/O module
from the sampler or flow logger. Make sure that the I/O module is sufficiently near the sampler or flow
logger to connect the I/O module cable to the sampler or the flow logger.
Refer to
Figure 2
to attach the I/O module to a wall. Refer to
sampler.
Figure 2 Wall mounting
N O T I C E
Figure 3
to attach the I/O module to a
English 7
