1. Remove the funnel from its packaging.
2. Hold the funnel using the grip areas on the sides and attach it
firmly to the top of the device (it can only point in one direction).
3. Ask the subject to blow evenly and without interruption into the
funnel without touching it.
 A continuous tone signals a sufficient flow of air.
 While the sample is being taken, an animated circular progress
bar that indicates progress as a percentage value is displayed
(see Figure 2 on the fold-out page: B, C).
 If sampling was successful, the tone ends with a clear, audible
click.
 The display shows a spinning progress bar during an ongoing
analysis process.
 The result is displayed after a few seconds and stored by the
device.
4.7.2 Reading the result
● If alcohol is detected, the message ALCOHOL is displayed and
the red LED lights up.
● If no alcohol is detected, the message NO ALCOHOL is displayed
and the green LED lights up.
● Press the
4.8 Turning off the device
● Hold down the
The device will switch off automatically approx. 4 minutes after the
last use.
4.9 Removing the mouthpiece
● Push the mouthpiece on the mounting spacer out of the
mouthpiece receptacle in an upward motion and dispose of it (see
fold-out page, Figure A).
®
Dräger Alcotest
button to continue with the next measurement.
button for about 3 seconds.
