Description
1
8
6
12
(
SJ-WX830F: 5 pcs
1. Door pocket
SJ-SX830F: 6 pcs
2. Refrigerator shelf
3. 9 way shelf (See the next page.)
4. Fixed shelf
5. Vegetable case
Moisture cover is installed on the right side only.
This cover works for storing food with high-moisture
freshly.
Moisture cover (Unremovable)
Fixed shelf
6. Egg holder
7. Fresh case
8. Water tank (Ice maker)
9. Dispenser tank <Only for SJ-WX830F>
10. Case
11. Stainless steel tray
12. Ice storage box
To prevent damage to the ice storage box, do not
make ice in the ice storage box or pour oil into it.
13. Freezer shelf
15 4 17 15 15
3 15 16 2
13
SJ-WX830F
)
Vegetable case
9
1
5
7
10
11
18
14
19
14. Freezer case
15. Light
16. Plasmacluster indicator
17. Hybrid cooling panel
The panel cools the refrigerator compartment
indirectly from the rear. In this way, food is cooled
gently without being exposed to cold air flow.
18. Control panel
19. Motion sensor (See the next page.)
20. Water dispenser <Only for SJ-WX830F>
21. LED Indicator
The light reacts differently by opening refrigerator
door, freezer door (left) or using control panel. The
pattern of lighting depends on the preset temperature
of multi temperature room or operating mode.
If you wish to store large items within your
refrigerator
• You may remove any shelves or any pockets numbered
1, 2, 3, 5, 6, 7, 8, 10, 11, 12, 13, 14 in the picture above.
• Cooling performance is not influenced even if you use
the refrigerator in the above situation.
1
SJ-SX830F
20
21
EN
EN-4
