AB
BC
CA

3-7. LCD Setting

There are three parameters to set up the UPS. Refer to following diagram.
Parameter 1
Parameter 2
Programs available list for parameter 1:
Code Description
01 Output voltage
02 Output frequency
03 Voltage range for bypass
04 Frequency range for bypass
05 ECO mode enable/disable
06 Voltage range for ECO mode
07 Frequency range for ECO mode
08 Bypass mode setting
Maximum battery discharge time
09
setting
10 Reserved
11 Reserved
12 Neutral loss detection
13 Battery voltage calibration
14 Charger voltage adjustment
15 Inverter A voltage adjustment
16 Inverter B voltage adjustment
17 Inverter C voltage adjustment
18 Output A voltage calibration
19 Output B voltage calibration
Parameter 3
No Output mode
The first line
The second line
The third line
Parameter 1: It's for program alternatives. Refer
to below tables for the programs to set up.
Parameter 2 and parameter 3 are the setting
options or values for each program.
Note: Please select "Up" or "Down" button to
change the programs or parameters.
Bypass / AC
mode
Y*
Y
Y
Y
Y
Y
Y
Y Y
Y Y
Reserved for future options
Reserved for future options
Y Y
Y Y
Y Y
Y
Y
Y
Y
Y
17
ECO CVCF Battery
mode mode mode
Y Y Y
Y Y Y
Y Y Y
Y Y Y
Y Y
Y Y
Y Y
Y Y
Y Y
Battery
Test
Y
Y
Y
Y
