Start-up
• WA300 S4
• WA300 R S4/WA 300 AR S4
The device is an extension module and easily integrated
into compatible Hörmann drives.
• Remove the cover of the garage door drive (see
figure 2).
• Plug in the supplied connecting cable into con-
necting terminal (B) of the module (see figure 3).
• Plug the other end of the connecting cable into
the connecting terminal for the bus of the garage
door drive (see figure 4).
• Insert the module into the expansion slot of the
garage door drive provided (see figure 5).
• Put the cover back on (see figure 6).
5.2

Teaching-in

Read this entire section before starting the
teach-in procedure.
First set up your Homematic IP Access Point via
the Homematic IP app to enable operation of
other Homematic IP devices within your system.
For further information, refer to the operating
manual of the Access Point.
28
