1 General Information

6
Ethernet
7
Data
Items delivered
When you first unpack your LINEAR 5
In
that it comes complete with the Quick Start Guide, a PowerCon mains cable,
instructions for safe commissioning and an RCS (Rain Cover Set).

2 Connections and controls

Input
4
1
5
DSP Out
LINEAR 5 308 LTA
MK II
4
L
1
LINEAR 9 iA
Input
4
112 XA
R
1
MADE IN GERMANY
5
DSP Out
Caution: Risk of electric shock! Do not open!
LINEAR 5 Refer servicing to qualified service personnel. 118 Sub HPA
MK II
Attention: Risque de choc élèctrique –
ne pas ouvrir!
●
1
Input
XLR/jack combo socket, balanced input for analogue signals.
• The mid/high model has one input channel.
• The subwoofer has two separate inputs for the left and right signals. The
two channels are equal and summed post-preamp, so you can use either
HK Audio is a brand of Stamer Musikanlagen GmbH
one in mono mode.
Magdeburger Str. 8 • 66606 St. Wendel • Germany
●
2
Power Mains Input
Thru
100-240 V~ 50-60 Hz
1 A @ 1/8 output power
Use this parallel, balanced XLR output to send the signal routed into the
LINEAR 7
Input through to other components. This output remains active even when
the electronic components are deactivated. The subwoofer has two of these
118 Sub A
ports.
MADE IN GERMANY
4
Power
Auto Sleep 1
On Off
2
8
3
Preset
4
Remote
speaker cabinet, please check
MK II
Thru Gain
0 dB
2 3
10
+6 dB
Power
Auto Sleep
On Off
13
2
Thru Gain
0 dB
3
2
–6 dB +6 dB
Serial No.
Lock
●
3
Gain
Use this knob to adjust the input gain for the incoming signal.
• For the mid/high model –∞ (Mute) to +6 dB
• This knob adjusts the gain for both of the subwoofer's stereo preamp
channels in a range of -6 to +6 dB.
The centre-notched 12 o'clock position is 0 dB in both cases.
Note: The Gain setting does not affect the signal sent to the DSP Out.
●
4
Input/Limiter LED
This LED lights up green to indicate incoming signals. When it is red, either
the limiter is active or the input is clipping. The LED briefly flashes red to
tell you the Limiter is responding to signal peaks. If it stays red, turn down
the Gain knob.
●
5
DSP Out
Balanced XLR socket, used to output the analogue input signal (coming
from the Input socket). The signal can be processed with the internal DSP
using the DSP CONTROL software. This means the DSP Out can serve as a
network interface that lets you integrate an added powered speaker that
is not originally network-compatible. In the factory default configuration,
the unprocessed input signal goes straight to DSP Out, regardless of the
selected preset and the Gain knob setting.
Thru
6
Ethernet
7
Data
In
●
6
Ethernet In /Thru
Use the two etherCON ports to integrate the speaker into a network. They
Input
accept RJ45 and etherCON (NE8 MX, NE8 MX6, NE8 MC) plugs. Use the
4
Ethernet Thru port to forward the network signal.
1
Always use S/STP or S/FTP cables to shield against electromagnetic inter-
ference. We recommend CAT6 cables. A separate manual explains the finer
points of network integration and remote control functions. You will find
it on the LINEAR 5 download page at www.hkaudio.com. For a brief
MK II
description of the DSP functions, see section
5
●
7
Data
This LED lights up orange when data is being transferred via the network
DSP Out
socket.
Power
1
Auto Sleep
On Off
2
8
3
