Technical Specifications - HK Audio LINEAR 5 MK II Bedienungsanleitung

LINEAR 5 308 LTA 1.0
MK II

7 Technical Specifications

Model
Max. SPL @ 10 % THD
Max. SPL Peak @ 10 % THD
Frequency response +/-3 dB
Frequency response -10 dB
Power amp output (RMS/Peak)
Amplifier type
Woofer
Low/mid speaker
HF driver
Horn characteristics
Active x-over frequency
Maximum input level
Analogue inputs
Analogue Thru
DSP Out
Network port
Filter presets
Remote software
DSP functions
Sample rate
System latency
Mains connection
Power consumption
Setup angle
Pole mount
Rigging points
Carrying handles
Housing
Surface
Front grille
Dimensions (WxHxD)
Weight
11
LINEAR 5
308 LTA
MK II
133 dB half space
(100 Hz – 12 kHz averaged)
138 dB half space
105 Hz – 17 kHz
98 Hz – 19 kHz
600 / 1,200 W
Class D – bi-amped
-
3 x 8", 1.5" voice coil
1" compression driver, 1.7" voice coil
60° x +5/-25° MCT horn
1.6 kHz FIR X-over with 60 dB/oct.
20 dBu
1 x XLR combo balanced
1 x XLR balanced
1 x XLR balanced
EtherCON RJ45, 1 x In, 1 x Thru
Single, Cluster, Headstack, Remote
DSP CONTROL (Windows, Mac OS)
Fully parametric 10-band EQ with variable filter
characteristics, High-Pass Filter, Low-Pass Filter,
Polarity, Level, Delay, Limiter, Mute
48 kHz
<= 2.9 ms
1 x PowerCon NAC3 In, 1 x PowerCon NAC3 Thru,
100–240 V
1 A / 100–240 V nominal according to EN 62368-1
-
MonoTilt 0°
5 x M8 (AP-8)
2 x MultiGrip
Birch multiplex
Black acrylic enamel
2 mm metal grille backed with black acoustic foam
44 x 68 x 46 cm
17-21/64 x 26-49/64 x 189-7/64"
25 kg / 55.1 lbs
LINEAR 5
118 Sub HPA
MK II
130 dB half space
(36 Hz – 100 Hz averaged)
131 dB half space
36 Hz – X-over
33 Hz – X-over
1,500 / 3,000 W
Class D
1 x 18", 4" voice coil
-
-
-
-
20 dBu
2 x XLR combo balanced
2 x XLR balanced
1 x XLR balanced
EtherCON RJ45, 1 x In, 1 x Thru
Front, Cardioid 1:1 vertical, Cardioid 2:1 vertical,
Remote
DSP CONTROL (Windows, Mac OS)
Fully parametric 10-band EQ with variable filter
characteristics, Low-Pass Filter, Polarity, Level, Delay,
Limiter, Mute
48 kHz
<= 2.6 ms
1 x PowerCon NAC3 In, 1 x PowerCon NAC3 Thru,
100–240 V
2.5 A / 100–240 V nominal according to EN 62368-1
-
1 x M20
-
4 x MultiGrip
Birch multiplex
Black acrylic enamel
2 mm metal grille backed with black acoustic foam
61 x 61 x 79 cm
24-1/64 x 24-1/64 x 31-7/64"
53.4 kg / 117.2 lbs
