Spezifikationen
linesensor {line_num} {energy_sensor} publish
delta show
linesensor {line_num} {energy_sensor}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port set {port_num}
linesensor {line_num} {energy_sensor}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} port show
linesensor {line_num} {energy_sensor}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state set {OFF=0|ON=1|
DISABLED=2}
linesensor {line_num} {energy_sensor}
{BELOWMIN=0|ABOVEMIN=1|ABOVEMAX=2|
BELOWMAX=3} state show
linesensor {line_num} events set {OFF=0|ON=1}
linesensor {line_num} events show
linesensor {line_num} events type set
"{EVT_SYSLOG=0,EVT_SNMP=1,EVT_EMAIL=2
,EVT_SMS=3,EVT_GSMEMAIL=4,EVT_BEEPER
=5,EVT_DISPLAY=6,EVT_CONSOLE=7,EVT_M
QTT=8}"
linesensor {line_num} events type show
linesensor {line_num} maxval set {float}
linesensor {line_num} maxval show
linesensor {line_num} minval set {float}
linesensor {line_num} minval show
linesensor {line_num} hyst set {float}
linesensor {line_num} hyst show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
port set {port_num}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
port show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state set {OFF=0|ON=1|DISABLED=2}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state show
linesensor beeper set {OFF=0|ON=1}
linesensor beeper show
modbus
modbus enabled set <off=0/on=1>
modbus enabled show
modbus port set <ip_port>
modbus port show
mqtt
mqtt {broker_idx} enabled set {OFF=0|ON=1}
mqtt {broker_idx} enabled show
mqtt {broker_idx} server set "{dns_name}"
mqtt {broker_idx} server show
mqtt {broker_idx} tls enabled set {OFF=0|ON=1}
mqtt {broker_idx} tls enabled show
mqtt {broker_idx} port set {ip_port}
mqtt {broker_idx} port show
mqtt {broker_idx} user set "{username}"
mqtt {broker_idx} user show
mqtt {broker_idx} passwd set "{passwd}"
mqtt {broker_idx} passwd hash set "{passwd}"
mqtt {broker_idx} client set "{name}"
mqtt {broker_idx} client show
mqtt {broker_idx} qos set {QOS0=0|QOS1=1}
mqtt {broker_idx} qos show
mqtt {broker_idx} keepalive set {num_secs}
mqtt {broker_idx} keepalive show
mqtt {broker_idx} topic set "{name}"
mqtt {broker_idx} topic show
mqtt {broker_idx} console enabled set {OFF=0|
ON=1}
mqtt {broker_idx} console enabled show
mqtt {broker_idx} device data timer set
{num_secs}
mqtt {broker_idx} device data timer show
73
Expert Power Control 8031/8035
shows publish delta value
sets Port for Power Port Switching actions
shows Port for Power Port Switching actions
sets Port state for Power Port Switching actions
shows Port state for Power Port Switching actions
LEGACY - enables events on/off
LEGACY - shows if events are enabled
LEGACY - enables different event types
LEGACY - shows what event types are enabled
LEGACY - sets maximum value for line meter
LEGACY - shows maximum value for line meter
LEGACY - sets minimum value for line meter
LEGACY - shows minimum value for line meter
LEGACY - sets hysterese value for line meter
LEGACY - shows hysterese value for line meter
LEGACY - sets Port for Power Port Switching
actions
LEGACY - shows Port for Power Port Switching
actions
LEGACY - sets Port state for Power Port
Switching actions
LEGACY - shows Port state for Power Port
Switching actions
enables beeper for line meter alarms
shows if beeper for line meter alarms is enabled
enters cmd group "modbus"
enables Modbus TCP support
shows if Modbus is enabled
sets Modbus TCP port
shows Modbus TCP port
enters cmd group "mqtt"
enable mqtt
shows if mqtt enabled
sets broker name
shows broker name
enable TLS
shows if TLS enabled
set broker TCP/IP port
shows broker TCP/IP port
sets username
shows username
sets password
sets hashed passwd
sets client name
shows client name
sets QoS level
shows QoS level
sets keep-alive time
shows keep-alive time
sets topic prefix
shwos topic prefix
permit console cmds
shows if console cmds allowed
sets telemetry interval
shows telemetry interval
L
L
L
L
L
L
L
L
L
L
L
L
L
L
