Spezifikationen
epc8035spActivePowerChan
epc8035spPowerIndex
epc8035spChanStatus
epc8035spAbsEnergyActive
epc8035spPowerActive
epc8035spCurrent
epc8035spVoltage
epc8035spFrequency
epc8035spPowerFactor
epc8035spPangle
epc8035spPowerApparent
epc8035spPowerReactive
epc8035spAbsEnergyReactive
epc8035spAbsEnergyActiveResett
able
epc8035spAbsEnergyReactiveRes
ettable
epc8035spResetTime
epc8035spForwEnergyActive
epc8035spForwEnergyReactive
epc8035spForwEnergyActiveReset
table
epc8035spForwEnergyReactiveRe
settable
epc8035spRevEnergyActive
epc8035spRevEnergyReactive
epc8035spRevEnergyActiveResett
able
epc8035spRevEnergyReactiveRes
ettable
epc8035CPUSensorVsystem
epc8035CPUSensorVaux
epc8035CPUSensorVmain
epc8035CPUSensorTcpu
epc8035NTPTimeValid
epc8035NTPUnixTime
epc8035NTPLastValidTimestamp
epc8035RCMBInfoIndex
epc8035RCMBCurrentRMS
111
Expert Power Control 8031/8035
shows the status of the built-in Overvoltage Protection
.83.1.5.5.1.0
Number of Single Port Power Channels. Value is zero on EPC 8220
series.
.83.1.5.5.2.1.1.x
Index of Single Port Power Channel entries. Indices 0-5 mean Ports A1
to A6, 6-11 are Ports B1 to B6.
.83.1.5.5.2.1.2.x
0 = data not active, 1 = data valid
.83.1.5.5.2.1.3.x
Absolute Active Energy counter.
.83.1.5.5.2.1.4.x
Active Power
.83.1.5.5.2.1.5.x
Actual Curent on Power Channel.
.83.1.5.5.2.1.6.x
Actual Voltage on Power Channel
.83.1.5.5.2.1.7.x
Frequency of Power Channel
.83.1.5.5.2.1.8.x
Power Factor of Channel between -1.0 and 1.00
.83.1.5.5.2.1.9.x
Phase Angle between Voltage and L Line Current between -180.0 and
180.0
.83.1.5.5.2.1.10.x
L Line Mean Apparent Power
.83.1.5.5.2.1.11.x
L Line Mean Reactive Power
.83.1.5.5.2.1.12.x
Absolute Reactive Energy counter.
.83.1.5.5.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.83.1.5.5.2.1.14.x
Resettable Absolute Reactive Energy counter.
.83.1.5.5.2.1.15.x
Time in seconds since last Energy Counter reset.
.83.1.5.5.2.1.16.x
Forward Active Energy counter.
.83.1.5.5.2.1.17.x
Forward Reactive Energy counter.
.83.1.5.5.2.1.18.x
Resettable Forward Active Energy counter.
.83.1.5.5.2.1.19.x
Resettable Forward Reactive Energy counter.
.83.1.5.5.2.1.20.x
Reverse Active Energy counter.
.83.1.5.5.2.1.21.x
Reverse Reactive Energy counter.
.83.1.5.5.2.1.22.x
Resettable Reverse Active Energy counter.
.83.1.5.5.2.1.23.x
Resettable Reverse Reactive Energy counter.
.83.1.5.14.1.0
System Voltage on CPU Board
.83.1.5.14.2.0
Auxiliary Voltage on CPU Board
.83.1.5.14.3.0
Main Voltage on CPU Board
.83.1.5.14.4.0
Temperature on CPU Board
.83.1.5.15.1.0
Show if valid Time is received
.83.1.5.15.2.0
show received NTP time as unixtime (secs since 1 January 1970)
.83.1.5.15.3.0
show seconds since last valid NTP timestamp received
.83.1.5.16.1.1.x
Index of RCMB Info entries
.83.1.5.16.1.2.x
Actual Residual Current RMS on Power Channel. According Type B IEC
Unsigned32
RO
Integer32
RO
Integer32
RO
Gauge32
RO
Integer32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Integer32
RO
Integer32
RO
Integer32
RO
Integer32
RO
Gauge32
RO
Gauge32
RW
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Gauge32
RO
Integer32
RO
INTEGER
RO
Unsigned32
RO
Unsigned32
RO
Integer32
RO
Unsigned32
RO
© 2023 GUDE Systems GmbH
