Spezifikationen
epc8035PortStartupMode
epc8035PortStartupDelay
epc8035PortRepowerTime
epc8035PortResetDuration
epc8035Buzzer
epc8035ActivePowerChan
epc8035PowerIndex
epc8035ChanStatus
epc8035AbsEnergyActive
epc8035PowerActive
epc8035Current
epc8035Voltage
epc8035Frequency
epc8035PowerFactor
epc8035Pangle
epc8035PowerApparent
epc8035PowerReactive
epc8035AbsEnergyReactive
epc8035AbsEnergyActiveResettab
le
epc8035AbsEnergyReactiveResett
able
epc8035ResetTime
epc8035ForwEnergyActive
epc8035ForwEnergyReactive
epc8035ForwEnergyActiveResetta
ble
epc8035ForwEnergyReactiveRese
ttable
epc8035RevEnergyActive
epc8035RevEnergyReactive
epc8035RevEnergyActiveResettab
le
epc8035RevEnergyReactiveResett
able
epc8035ResidualCurrent
epc8035LineSensorName
epc8035OVPIndex
epc8035OVPStatus
Expert Power Control 8031/8035
The total number of switch actions ocurred on a Relay Port. Does not
count switch commands which will not switch the ralay state, so just real
relay switches are displayed here.
.83.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.83.1.3.1.2.1.6.x
Delay in sec for startup action
.83.1.3.1.2.1.7.x
Delay in sec for repower port after switching off
.83.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.83.1.3.10.0
turn Buzzer on and off
.83.1.5.1.1.0
Number of suppported Power Channels.
.83.1.5.1.2.1.1.x
Index of Power Channel entries
.83.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.83.1.5.1.2.1.3.x
Absolute Active Energy counter.
.83.1.5.1.2.1.4.x
Active Power
.83.1.5.1.2.1.5.x
Actual Curent on Power Channel.
.83.1.5.1.2.1.6.x
Actual Voltage on Power Channel
.83.1.5.1.2.1.7.x
Frequency of Power Channel
.83.1.5.1.2.1.8.x
Power Factor of Channel between -1.0 and 1.00
.83.1.5.1.2.1.9.x
Phase Angle between Voltage and L Line Current between -180.0 and
180.0
.83.1.5.1.2.1.10.x
L Line Mean Apparent Power
.83.1.5.1.2.1.11.x
L Line Mean Reactive Power
.83.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.83.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.83.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.83.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.83.1.5.1.2.1.16.x
Forward Active Energy counter.
.83.1.5.1.2.1.17.x
Forward Reactive Energy counter.
.83.1.5.1.2.1.18.x
Resettable Forward Active Energy counter.
.83.1.5.1.2.1.19.x
Resettable Forward Reactive Energy counter.
.83.1.5.1.2.1.20.x
Reverse Active Energy counter.
.83.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.83.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.83.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.83.1.5.1.2.1.24.x
Actual Residual Current on Power Channel. According Type A IEC
60755. Only visible on models that support this feature.
.83.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.83.1.5.2.1.1.x
None
.83.1.5.2.1.2.x
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Unsigned32 RO
OCTETS RW
Integer32 RO
INTEGER RO
