Faber PREMIO ANG/SP 100x100 RVS/GLAS Bedienungsanleitung Seite 7

CHARACTERISTICS
Ref. Q.ty Product Components
1 1 Hood Body, complete with: Controls, Light, Blower,
Filters
2 1 Telescopic Chimney comprising:
2.1 1 Upper Section
2.2 1 Lower Section
9 1 Reducer Flange ø 150-120 mm
14.1 2 Air Outlet Connection Extension
15 1 Air Outlet Connection
Ref. Q.ty Installation Components
7.1 1 Hood Connector Support
7.2.1 2 Upper Chimney Section Fixing Brackets
11 12 Wall Plugs
12a 12 Screws 4,2 x 44,4
12e 6 Screws 2,9 x 9,5
12r 2 Screws 4,2 x 12,7
Q.ty Documentation
1 Instruction Manual
EN
Dimensions
Components
ø150
ø120
15
9
2.1
2
2.2
12r
1
14.1
7.2.1
11
12a
12e
12a
11
7.1
7
7
