HumanTechnik signolux Bedienungsanleitung Seite 10

Figure 1: View of top / side / front
Function button 2
Function button 1
Microphone
grille
On/Off-
switch
Figure 2: View of underside
10 English
Function button 3
Front cover
of battery compartment
Microphone-
status-LED
Batterystatus-
LED
Transmission-
LED
(all LEDS are
located under
the front cover)
7.5V-connection
socket
