Operation And Settings; Daily Operations - Waterdrop Wd-Ed01W Gebrauchsanweisung

Daily Operations

Water
outlet
Figure 4
Charging
Port
Figure 5
Filter Life and Replacement Guideline
a. Filter Life
Model: WD-EDF
Filter Life: Up to 3 months or 757L
NOTE: The filter life may vary based on water consumption and water quality.
b. Filter Replacement Guide
Figure 6 Figure 7
Figure 8
Figure 9

Operation and Settings

Water Taking
• Put a container or a cup under the water outlet, activate the screen by clicking the water
dispensing key " ", and click it again to dispense water. (Figure 4)
• After taking water, click the water dispensing key " " again to pause water dispensing.
NOTE: This system comes with a long-time water taking protection function.
After over 3 minutes of continuous water dispensing, the system will buzz once and
automatically stop running.
Charging
• The power indicator on the display screen of the system flashes red to signal low battery,
and charge the system by using a 5V 2A adapter and inserting a USB Type-C Cable into
a side charging port of the water pumping unit. (Figure 5)
• After charging is done, the power indicator on the display screen stops flashing green
and turns solid green.
NOTE: Please charge the system by using a 5V 2A power adapter. The system can
be used while being charged, and the charging time may last for 4-5 hours. If the
charging current is smaller than 2A, the charging time will be prolonged beyond
expectations and the simultaneous charging and usage functions will be disabled. If you
need a 5V 2A adapter, please feel free to contact our customer service by calling
+1-888-352-3558 or sending an email to service@waterdropfilter.com.
• To remove the old filter, take out the water pumping unit (Figure 6), and push the bottom
of the filter upwards to loosen the filter from the water pumping unit. Then, press the
buckles on both sides of the filter to take the filter out of the water pumping unit. (Figure 7)
NOTE: There may be a small amount of water flowing out of the water pumping unit
when pulling out the filter, so be sure to place a container underneath. (Figure 8)
• Remove the filter package and the paperboard on two sides, align the buckles of the
filter to notches of the water pumping unit, and insert a new filter. After the new filter is
installed in place, the bottom of the filter is aligned with that of the water pumping unit,
and there is a slight mechanical sound. (Figure 9)
• Hold the water dispensing key "
successfully reset, the filter life indicator turns blue.
• After filter reset, it is highly recommended to flush it for at least 3 minutes before using.
NOTE: For better filtration, activate the filter first by flushing. When using it for the first
time or after replacing it, please discard the first tank of filtered water and do not drink it.
" for 3 seconds for filter resetting, and after the filter is
4
