4. Mounting

The Remote Controller has been installed – fig. 2
When the Remote Controller has been installed to the
Master Controller (see 2), it can be mounted on the wall by means of
the back plate/docking station . This makes it possible to connect the
Remote Controller to a 20V power supply with the included trans-
former/power supply plug . When it is not in the docking station, the
Remote Controller is powered by two AA Alkaline .5V batteries.
• Before you place the back plate/docking station on the wall, verify the
transmission to the Master Controller from the desired location by car-
rying out a link test (see )
• Mount the back plate/docking station on the wall with the screws and
wall plugs
• Connect the docking station to a 20V power supply outlet by means
of the transformer/power supply plug
• Place the Remote Controller in the docking station
Note: To extend the transmission range of the CF2 system, up to three
Repeater Units can be installed in a chain – see fig. 4
