Instruction CF-RC Remote Controller

2. Installation

Note:
• Install the Remote Controller after you have installed all the Room
Thermostats, see fig. 5 b
• Remove the strip to connect the enclosed batteries
• Carry out the assignment of the Remote Controller to the Master Control-
ler within a distance of 1½m
• When the back light in the display is out, the first touch of a button only
activates this light
Activate Install mode on the Master Controller - fig. 3
• Use the menu selection button
LED flashes
• Activate Install mode by pressing OK . The install LED
Activate Install mode on the Remote Controller
• When the batteries have been connected, follow the installation
guide, beginning with the selection of language
• After the installation process, set time and date. Use the up/down
selector
). Confirm settings with OK activated by soft key  (fig. - )
• The installation process is concluded with the opportunity to name
the rooms in which the Room Thermostats are placed. This makes ac-
cess to and handling of the system very easy
• In the Name rooms menu, activate the change menu with soft key 2
(fig. - ) to change the default room names from e.g. MC Output .2
(Master Controller , output  and 2) to living room, and confirm with
OK. You can also use the spell.... menu to create other names
6
VI.UH.M3.80
and the left/right selector
Produced by Danfoss Floor Heating Hydronics 02.2006
to select the Install mode. The install
to carry out the settings (fig.
goes ON
