Dismantle the roller shutter drive
If you have to remove the roller shutter
drive due to relocation or renovation,
proceed as follows:
1.
Press the DOWN button and close
the roller shutter completely.
2.
Press the Reset button for about 2
seconds to delete the end stops.
Note
The indicator light fl ashes briefl y.
3.
Repeatedly press the DOWN but
ton and keep it pressed.
4.
Now pull the webbing from the
roller shutter drive by hand using
the pulley as far as possible to the
front.
20
5.
R e m o v e t h e c o v e r p l u g .
By pressing lightly on its lower half,
the cover plug tilts slightly from its
holder.
6.
Loosen the mounting screws and
pull the roller shutter drive from
the belt box.
7.
Remove the webbing cover.
8.
Check the position of the moun-
ting hook, so that you can easily
remove the webbing.
Note
If necessary, move the hook into
the correct position to remove the
webbing.
Risk of injury through the
winding wheel, if you reach
into the mounting hole
with the motor running.
Pull out the power plug
before you reach into the
mounting hole.
9.
9.
Loosen the webbing from the
mounting hooks of the winding
wheel and pull it forward out of the
roller shutter drive.
