Installing the roller shutter drive
1.
Slide the roller shutter drive into the
belt box.
Note
Install the roller shutter drive
straight, so that the webbing can
wind correctly. Make sure that the
unit sits freely in the belt box, as
this may cause noise, especially if
the roller shutter drive rests
against the masonry.
2.
Firmly attach the roller shutter
drive top and bottom with the
enclosed screws.
Make sure that the mains
cable lies properly in the
cable channel. Or else it
can cause damage while
screwing on.
3.
Press the attached cover plug into
the bottom screw hole.
11
