Digisystem, How to Use the Property Connection Set
6
6.1
Description
6.2
Property Connection
Set main parts

How to Use the Property Connection Set

General Information

The Property Connection Set provides a safe technique of applying a traceable signal to live
electricity cables. It is connected to the service via a mains plug outlet and provides a trace-
able signal. Supply is not interrupted by the applied signal and the risk of serious injury is
greatly reduced.

Property Connection Set Overview

a
b
a) Mains plug connector
c
b) In line isolator
c) Transmitter plug connector
46
