1. Mechanical Construction

1.1 Enclosure
Dimensions: 151 x 125 x 60 mm.
Material: PC UL 94 V0 (material is suitable for outdoor use;
f1-listing according to UL 746C).
Seal: PU, foamed.
Colour: Graphite grey, similar to RAL 7024.
Mounting type: Wall mounted. 4 drilling holes on the back
of the enclosure base. Indoor use only.

1.2 Cable entry

3 x PG9 cable glands
2 x M12 cable glands
1 x M12 blanking cap (spare port for additional M12 cable gland)
All cable glands include locknut and rubber washer.

1.3 Additional equipment

1 x M12 vent plug for pressure compensation

2. Technical specification

WatchmanFlo
Dimensions
Material
Mounting type
Power supply
Ambient temperature
Humidity
Fuse
Buzzer
Relays
Flo
Specifications
151 x 125 x 60 mm
PC UL 94 V0
Wall mounted
110 ÷240VAC, 50/60Hz 10VA or 24VDC, 1A
-20°C ÷ +40°C
15% - 95%
TR5, 1A, Time delay
93dB mounted inside
HFE 1C SPCO 24VDC
Contact rating: 10A 240VAC/24VDC
1HP 240VAC
