ELMECO First Class FC1 Gebrauchs- Und Wartungshandbuch Seite 85

I
1: Interruttore
generale
Pr: Pressostato
LPr: Spia
pressostato
TM: Timer
(Opzionale)
8: Interruttore timer
C: Compressore
FM:
Motoventilatore
TR: Trasformatore
7: Fusibile 5x20
mm (2A-20VA/5A-
60VA)
9: Fusibile 5x20
mm F315mA
EV1-2-3:
Elettrovalvola
M1-2-3:
Motoriduttore
EB1-2-3: Modulo
elettronico
EM: Modulo
macchina
H1-2-3: Lettore
ottico o magnetico
L1-2-3: Lampada
cupola
P1-2-3: Sonda
livello
R1-2-3:
Resistenza
100Kohm-0.25W
A: Filtro
antidisturbo
(230V/50HZ)
q1-2-3:
Termostato
B: Condensatore
rifasamento (FC3
120V/60HZ)
Colori
BRN Marrone
BLU Blu
GRN Giallo-Verde
RED Rosso
BLK Nero
WHI Bianco
GRY Grigio
VIO Viola
ORA Arancione
GB
1: Main switch
Pr: Pressure
switch
LPr: Pressure
switch light
TM: Timer
(Optional)
8: Timer switch
C: Compressor
FM: Fan motor
TR: Transformer
7: Fuse 5x20 (2A-
20VA/5A-60VA)
9: Fuse 5x20 mm
F315mA
EV1-2-3: Solenoid
valve
M1-2-3: Gear
motor
EB1-2-3:
Electronic board
EM: Machine
module
H1-2-3: Magnetic
or Optical reader
L1-2-3: Top light
P1-2-3: Level
probe
R1-2-3: Heating
element 100Kohm-
0.25W
A: Suppressor
filter (230V/50HZ)
q1-2-3:
Thermostat
B: Phase
advancing
condenser (FC3
120V/60HZ)
Colors
BRN Brown
BLU Blue
GRN Yellow-
Green
RED Red
BLK Black
WHI White
GRY Grey
VIO Purple
ORA Orange
F
1: Interrupteur
général
Pr: Pressostat
LPr: Voyant
pressostat
TM: Temporisateur
(en option)
8: Interrupteur
temporisateur
C: Compresseur
FM:
Motoventilateur
TR:
Transformateur
7: Fusible 5x20
mm (2A-20VA/5A-
60VA)
- 83 -
9: Fusible 5x20
mm F315mA
EV1-2-3:
Électrovanne
M1-2-3:
Motoréducteur
EB1-2-3: Module
électronique
EM: Module
machine
H1-2-3: Lecteur
optique ou
magnétique
L1-2-3: Lampe
coupole
P1-2-3: Sonde de
niveau
R1-2-3:
Résistance
100Kohm-0.25W
A: Filtre
antiparasites
(230V/50HZ)
q1-2-3:
Thermostat
B: Correction du
facteur de
condensateur
(FC3 120V/60HZ)
Couleurs
BRN Brun
BLU Bleu foncé
GRN Jaune-Vert
RED Rouge
BLK Noir
WHI Blanc
GRY Gris
VIO Violet
ORA Orange
