Long Feet; First Class Millennium Controls And Signals - Elmeco First Class Fc1 Gebrauchs- Und Wartungshandbuch

Long feet

(only for 115Vac/60Hz)
The units First class 2 and First
Class 3 with voltage
115Vac/60Hz are equipped
with 4 long feet (4 inches) that
must be installed at the place of
the short 4 feet already
mounted.
This installation is obligatory in
conformity of NSF rules.
This long feet aren't adjustable
in height.
First Class Millennium
controls and signals
When you switch on the
electronic board, the display will
show
ELMECO / ITALIA
(0.15)
Where 0.15 indicates the tank
review number.
FC Millennium has a BASIC
version that only has the
electronic board like the one
shown before, and an
ADVANCED version that ha
san additional electronic kit in
the machine with additional
features connected to time.
Warning: The screen with the
"/" symbol indicates that the
values are shown
alternatively.
After the screen shown above
the initial screen will be
displayed:
- 22 -
StandBy
Press
WARNING: The electronic
board will keep the settings it
had when the machine was
switched off.
When the tank is in stand-by
mode, the augers and the
cooling system are off. The
augers and the gear motor can
be turned on by pressing the
button. The screen will
show:
Motor on
Press < <> >
If you press the button, the
screen will display as follows:
Select / Degrees /
YY
(where YY is a variable number
between 02 and 05 for Cold
Drink Mode, which indicates the
temperature in ° C at which the
product must be prepared).
Using and you can
increase or decrease the
temperature of the product. The
recommended temperature is
4° C.
If you press the button, the
screen will display as follows:
Select / Density /
*
X
(where X is a variable number
between 1 and 9 and indicates
the density of the slush). If you
use the and buttons it is
possible to increase or
decrease the slush density
value.
--
--
