1 Channel
• Set sliding
Permanently ON
switch
position I.
The appliance(s)
connected is(are)
The symbol
•
permanently
shows in
switched on
Display.
Permanently OFF
• Set sliding
switch
The appliance(s)
position 0.
connected is(are)
The symbol
permanently
•
extinguished.
switched off
• Set sliding
switch
position AUTO.
AUTO
• ON Mode:
The appliance(s)
symbol
connected switch
appears.
according to a pre-
set programmer
OFF Mode:
•
symbol
extinguished.
Programming Switching Times
Each Channel has 16 programmable
Switching Points (8 x ON, 8 x OFF):
Nos. 1, 3, 5, 7, 9, 11, 13, 15 are Switch
ON points (symbol ).
Nos. 2, 4, 6, 8, 10, 12, 14, 16 are
Switch OFF points (no symbol).
The Switch Time selected will be
indicated by a number in the lower
right of the Display and the symbol
1 Channel set-up
ON
OFF
Please note when programming:
Each switch on point is closely linked
to the following switch off point.
They should always be programmed in
pairs to avoid errors.
Attention: The shortest possible
switching interval is 1 minute!
Proceed as follows:
1. For 1 Channel set-up: Set sliding
switch to position .
P
The first switch point (switch on) is
displayed.
2. Press button 1...7 ( ) to input the
day of the week (1=Monday,
7=Sunday) or blocks of days.
Continuous pressing of this button
allows you to select individual days
to
and the following blocks of days:
1 to 5
1 to 6
Arrows in the Display indicate days
of the week.
to
3. Press buttons h ( ) and m ( ) to
set the time.
is
4. Press button
The next switch point (switch off) is
displayed.
to
5. Repeat steps 2 to 4 as often as
required.
6. After setting the desired switching
times: Set sliding switch
position AUTO and sliding switch
is
to position RUN.
The timer will now operate
according to the programmed
switching times.
Checking, changing and deleting
switching times
Set sliding switch
1. Checking:
Press button
necessary to show the desired
switching point in the Display.
.
2. Changing:
Use button
P
desired modified location.
Press buttons 1...7 ( ) to change
the day of the week.
Press buttons h ( ) and m ( ) to
change the switching time, as
described earlier.
3. Deleting:
P
Use button
desired modified location.
Then press button "-X->" ( ) and
button ( ) simultaneously for
P
3-4 seconds.
The Display will show a flashing
0:00 and the switching point is
deleted.
If the check, change or deletion is
complete set the sliding switch
to position RUN.
-X-> Skip Function (soft-override)
The Skip Function changes the
switching mode of the appliance
connected until the next step of
program is reached.
For instance: if the appliance is in ON
mode, pressing the Skip-button (-X->)
will immediately turn it OFF and vice-
versa.
- 98 -
1. Set sliding switch
2. Press the Skip button (-X->).
1 to 7
6 to 7
3. Further pressing of the Skip button
( ):
P
Please note in connection with the
Skip Function:
• Display of the number and the
symbol occurs after a lapse of about
3 seconds.
• The Skip Function only operates until
to
the next programmed switch time is
reached. At this point the Skip
Function is deleted and the
programmed switch time cycles are
activated again.
Every switch on point is closely linked
to the following switch off point.
P
to position .
Therefore the following combinations
of on/off switching can, for example,
lead to errors.
P as often as
Possible sources of errors are:
to flag up the
a)
b) No setting
c)
d) Day block
e)
to flag up the
f)
back
to position
RUN.
The appliance will change over to
the opposite switching mode.
The Skip symbol (-X->) show up in
the Display (wait 3-4 seconds).
(-X->) brings up the Skip Function
again.
Programming Errors
Switch ON Switch OFF
Time Time
Switch ON time
No setting
programmed
Switch OFF time
programmed
Different day
Day block (e.g. 1,
block (e.g. 1, 2, 3,
2, 3, 4, 5)
4, 5, 6)
Week day
Switch OFF time
Switch ON time is before the
programmed switch ON time
(e.g. Wednesday, on the same day
09:00) (e.g. Wednesday,
08:59)
ON and OFF switch times occur at the
same time (e.g. Wednesday, 09:00)
