7
Technical Data
Display
Type
Illumination Color
Number of Digits
Character Height
Polarity
Decimal Point
Overflow Display
Input
Module depending upon Model
Voltage Module
Input Resistance
Voltage Module
Voltage Drop
Resistance Module
Current to Resistance Path
Temperature Module Pt100
Sensor Current
Pressure Module
Measurement Signal
Bridge Supply
Min. Bridge Resistance
Error Limits
DC Module
Intrinsic Error
Temperature Coefficient
SMRR
CMRR
AC Module (arithmetic)
Intrinsic Error at 45 ... 65 Hz
30 ... 100 Hz
100 ... 1 kHz
Temperature Coefficient
1) MW = of measurement value
2) MB = of measuring range
24
7 segment LED
red, optionally green
–19,999 to 32,765
14 mm
"–" is displayed automatically
Programmable
-----
see serial plate
> 1 MΩ for measurements > 2 V
> 70 kΩ for measurements < 2 V
max. 2 V
200.0 Ω range:
2.000 kΩ range:
20.00 kΩ range:
2 mA for Pt100
2 / 3.3 / 20 mV/V
10 V for 2 / 3.3 mV/V sensor
5 V for 20 mV/V sensor
150 Ω for 2 / 3.3 mV/V sensor
100 Ω for 20 mV/V sensor
± (0.05 % + 1 D)
< 80 ppm/K
> 35 dB at 50 Hz
> 120 dB as related to MB 200.00 mV at 50 Hz
1)
± (0.2 % MW
+ 0.2 % MB
additional ± (0.2 % MW + 0.2 % MB)
additional ± (0.5 % MW + 0.2 % MB)
± (0.01 % + 0.01 mV) / K
1.5 mA
150 µA
15 µA
2)
)
GOSSEN-METRAWATT
