TOOLS REQUIRED

•
Socket set to include 12, 17 and 19mm
A/F sockets or spanners.
• Torque wrench (up-to 40Nm).
ITEM NO.
ITEM 1
ITEM 2
ITEM 3
ITEM 4
ITEM 5
ITEM 6 CRASH PROTECTORS (B0431 c/w CS340 and S0255)
ITEM 7
ITEM 8
ITEM 9
ITEM 10
ITEM 11
ITEM 12
ITEM 13
Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301
LEGEND
DESCRIPTION
CRASH PROTECTOR CAPS (BC0002)
M12 x 1.25 x 150mm LONG HEX HEAD BOLT
M12 WASHERS
SHAKE PROOF WASHERS (LW0001)
SPACER 74mm LONG (S1217)
RIGHT-HAND SJDE MOUNTING BLOCK (M0594)
SPACER 10mm LONG (S1216)
M12 x 1.25 x 70mm LONG HEX HEAD BOLT
M10 FLAT CAPS (NC0010)
M12 x 1.25 x 60mm LONG CAP HEAD BOLT
M8 FLAT CAP (NC0009)
M8 x 1.25 x 35mm LONG CAP HEAD BOLTS
R&G
GENERAL TORQUE SETTINGS
M4 BOLT = 8Nm
M5 BOLT =
M6 BOLT =
M8 BOLT = 20Nm
M 0 BOLT = 40Nm
1
M12 BOLT = 40Nm
www.rg-racing.com Email:
CP0475
2Nm
1
5Nm
1
QTY
2
1
2
2
1
2
1
1
1
1
1
1
1
