Device description
5
6
7
9
11
Fig. 4.2 Control panel
24
LED / Key
1 1 LED Plotter activ
2
LED Penstation
2
3
LED Plotter out of order
3
4
LED ON/OFF
4
5
Keys ON/OFF
6
UP/DOWN keys
7
Arrow keys
UP/DOWN/LEFT/ RIGHT
8 Key Penstation
8
9
LED Clear buffer
10 Key Clear buffer
10
11 LED STOP
12 Key STOP
12
Function / Display
Green: writing process active
Yellow: pen station open
Red: plotter operation error
Green: plotter ready for use, data
can be received from PC
Switch plotter on/off
Raise/lower plotter pen
The key STOP must be pressed be-
fore.
Move writing arm (four directions
along the writing surface)
The key STOP must be pressed be-
fore.
Open and close pen station
Yellow: data in plotter data memory
Delete data memory
Red: plotter was stopped
Stop and restart plotter
