DDR Motor Mounting Guide | Step 5: Remove and Secure Shipping Hardware
Step 5: Remove and Secure Shipping Hardware
Bolt
Screw
Bolt
Screw
Bolt
Screw
Screw
Bolt
Bolt
Screw
Step 6: Confirm Free Rotation
Step 7: Repalce End Cover
Your Kollmorgen Cartridge DDR
10
Screw
Bolt
Screw
Bolt
Screw
Bolt
Congratulations!
is ready for operation.
1. Remove four (4) shipping
bolts "B" and four (4) set
screws "C" using 6 mm hex
wrench.
2. Place shipping bolts and set
screws into foam holder.
1. Rotate load by hand to
ensure free movement.
1. Ensure the O-ring on the
outside of the end cover is in
place.
2. Rotate the end cover until the
alignment mark matches the
corresponding mark on the
housing.
3. Secure the end cover by
tightening the pan head
screws (eight (8) on the
C(H)09 and twelve (12) on
the C(H)13).
®
motor
Check
Here
