Figure 3 - Donning the ExoFit NEX™ Vest Style Full Body Harness
Step 1
Connection: Connect buckle ends by inserting
the tab into the receptor until a click is heard.
Strap Adjustment: Rotate Webbing Lock
to unlocked position
Rotate Webbing Lock to locked position .
NOTE: The Webbing Lock does not control
engagement or disengagement of the buckle ends.
Step 4
Step 2
Duo-Lok™ Quick Connect Buckles
. Pull strap to adjust.
Revolver™ Vertical Torso Adjusters
Right To Tighten: Turn
Ratchet Knob in
direction A.
To Loosen: Pull
A
Ratchet Knob
out and turn in
direction B.
NOTE: After
adjustment, tug
upwards on the
shoulder straps to
B
ensure that each
adjustor is locked in
place.
4
Step 3
Left
A
Step 5
B
