Product Overview - Conceptronic CSATAi23U Version 2.0 Benutzerhandbuch

1
4
Description of the numbers:
1. LED indicators
2. 2.5" IDE connector
3. Copy button
4. 3.5" IDE connector
5. eSATA connector
6. Mini-USB connector
7. Molex power connector
8. SATA connector
* If the eSATA connector is used for connection to your PC, you can only use the SATA connector on the
CSATAi23U. It is not possible to connect an IDE device to the CSATAi23U and access it through the
eSATA connection.

2. Product overview

2
5 6 7
Power, Activity and SATA LED's
Connect a 2.5" IDE Device
(Only works in combination with bundled software!)
Connect a 3.5" or 5.25" IDE Device
Connect the CSATAi23U to your PC through eSATA *
Connect the CSATAi23U to your PC through USB
For power to the CSATAi23U
Connect a 2.5", 3.5" or 5.25" SATA Device
3
2
ENGLISH
4
8
9
