HANDHELD TRANSMITTER:
14
1
4
2
5
3
6
7
MICROPHONE HEAD GRILL
1
GAIN
2
This button controls the sensitivity of the microphone
(rotation to the left reduces the sensitivity, rotation to
the right increases it).
The sensitivity is factory set to the optimum level
(for most applications).
RF SWITCH (RADIO SIGNAL)
3
"H" stands for "High" (strong signal), "L" for "Low"
(weak signal).
IR INTERFACE
4
BATTERY COMPARTMENT
5
Please insert 2 "AA" alkaline batteries (LR6, 1.5 V).
POWER/ASC
6
LED is static green: the microphone is switched on
LED flashes green: the infrared transmission is active
LED flashes red: Low Battery
ON/OFF SWITCH
7
REPLACING THE BATTERIES
If the battery LED light flashes, please replace the
batteries immediately.
