Step 3 Loosen the fixing of the existing switch on
the flush-mounted socket and carefully
pull the switch out. Release the wiring and
remove the existing switch if necessary.
Step 4 Connect the switched phase conductors
for connecting terminals 1 and 2 to the
motor as follows (see fig. 3):
Connecting terminal 1 (C) : "Down"
Connecting terminal 2 (D) : "Up"
Step 5 Connect the phase conductor to connect-
ing terminal L (B) .
Step 6 Connect the neutral conductor to con-
necting terminal N (E) .
Step 7 Connect the neutral conductor of the mo-
tor to the neutral conductor of the house
installation.
Step 8 Secure the blind actuator to the flush-
mounted box using the provided screws.
Please note that the system button (A) of
the actuator must be at the top left during
installation (see figure 4+5).
Step 9 Place the frame of your switch series on
the shutter actuator (see Fig. 6).
Step 10 Insert a suitable adapter in the frame on the
shutter actuator (see Fig. 7).
