Start-up
Permitted cable cross sections for connecting to the
blind actuator are:
rigid cable [mm
0.75 – 1.50
6.2 Installation
You can use the blind actuator in a blind, shutter or aw-
ning circuit. To install the blind actuator, please proceed
as follows:
Step 1
Step 2
44
2
] flexible cable with/without
ferrule [mm
0.75 – 1.50
Switch off the fuse of the power circuit (see
„6.1 Installation instructions" on page 42)
(see fig. 2).
If necessary, pull the rocker off the frame
of the relevant switch. Then pull the frame
off the switch together with the clamping/
retaining piece. The clamping/retaining
piece can be transparent, grey or black
depending on the manufacturer, and holds
the frame onto the switch.
To make removal easier, a flat, pointed
object such as a slotted screwdriver can
be used.
