Instruction Manual ESSG
___________________________________________________________________________

9. Technical Data

Safety cutting unit
Operating pressure:
Hydraulic oil:
Temperature range:
Cutting time:
Pump Type SHP 5
Total weight with battery:
Cutting force:
max. operating pressure:
Maximum cutting diameter:
Driving motor:
Motor voltage:
Charging time:
Cutting time:
Battery capacity
Cuts per battery:
Hydraulic oil:
environmental temperature:
Sound level:
Vibrations:
Insulating hose Type Europower (CIJN) 852
Inside diameter:
Outside diameter:
Min. bending radius:
dyn. Operating pressure:
min. burst pressure:
Weight with fittings:
Length between the fittings:
Cutting heads Type SSK
Head max. cable-∅ operating pressure
______________________________________________________________________________________________________
SSK 85/3
SSK 90/2
SSK 120/2 120 mm
Note
This instruction manual is available free of charge. The part # is HE.11094.
All manuals and user guides at all-guides.com
625 bar
"Special- Transformer Oil Rivolta S.B.H.11"
High grade bio-degradable, not hazardous to water
-20°C to 40°C
approx. 21s to 40s (depending on the cable size)
approx. 3,67 kg
60 kN
625 bar
85 mm (≅4x240 mm² sm)
direct-current permanent field motor
12 V DC
ca. 1 h or ¼ h with quick charger
approx. 21 s to 40 s
(depending on the cable diameter
2,6 Ah
approx. 17 cuts/battery
approx. 200 ml "Shell Tellus T 15"
-20°C to +40°C
70 dB (A) in 1m distance
< 2,5 m/s²
4 mm
13,2 mm
38 mm
689 bar
2758 bar
3,5 kg
10,3 m
85 mm 625 bar
90 mm 625 bar
625 bar
page 28
unit type Total weight
SSG 85/3 9,92 kg
SSG 90/2 13,85 kg
SSG 120/2 14,56 kg
