3. Warranty
If correct operation is guaranteed and regular service is provided our warranty is 1 year
from the time of delivery. Short circuit damages are excluded. The warranty does also not
cover the cutting blades which are subjected to ware within the determined use.
4. Description of the hydraulic safety cutting unit

4.1. Description of the components

The hydraulic safety cutting unit type ESSG consists of the following components:
Table 1 (see picture 1)
Pos.-No. Description
1 Drive unit
2 Light Diode Display
3 Connecting device
4 Trigger
5 Transportation lock
6 Release button
7 Key ring
8 Pressure gauge
9 Insulating hose
10 Bending protection
11 Cutting head
12 Cutting blades
13 Battery
14 Removable hand
guard
15 Grounding connection
4.2. Brief description of the important features of the unit
- The unit is equipped with a special brake which stops the forward motion of the
piston/blade (Pos.-No. 12) when the trigger (Pos.-No. 4) is released.
- The unit is equipped with a double piston pump which is characterised by a rapid
approach of the blades (Pos.-No. 12) towards the connector and a slow cutting motion.
- The cutting head (Pos.-Nr. 11) can be smoothly turned by 360° around the longitudinal
axis in order to gain better access to tight corners and other difficult working areas.
- The ESSG is equipped with a microprocessor which indicated service intervals, internal
checks and low battery charges.
All manuals and user guides at all-guides.com
Function
Main pump unit with pressure gauge and
grounding connection
indicator for tool functions (e.g. tool
LED
errors and Service) and battery charge control
To connect the high pressure hose to the pump
(consisting of male and female coupling)
switch to start cutting procedure
Hook to fix the trigger to avoid unintended
operation
To actuate the relief valve to return the oil into
the oil reservoir
Loop to secure the tool and/or for assembly
purposes
Scale indicating the operating pressure of the unit
Non conducting high pressure hydraulic hose
type Europower (CIJN) 852
Prevents that the minimum bending radius does
not fall short.
Working unit to cut cables and conductors
pivoting (a) and moveable (b) blades to cut not-
reinforced cables and conductors
rechargeable 2,6 Ah NiMH battery (RA4)
guard to protect the operating hand, not for
transportation
Hookup for the grounding pillow at the cutting
head and at the drive unit
page 19
See page
