Seite 2
Wir freuen uns, dass Sie sich für ein Klauke Thank you for choosing a Klauke tool. We hope Werkzeug entschieden haben und wünschen Ih- it gives you lots of pleasure. nen viel Freude damit. Sie haben ein Qualitätsprodukt „Made in You have purchased a quality product Germany“...
Seite 3
EK 60/22CFM optional: datecode FCC ID: RFRMS42 • IC: 4957A-MS42 Model: CFM WARNING This device complies with Part 15 of the FCC Rules and with Year Code Month Code Month Code Industry Canada licence-exempt standard(s). Operation is subject to the following two conditions: (1) this 2018 M Jan.
Seite 7
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le foncti- onnement. NOTICE: Changes or modifi cations made to this equipment not expressly approved by Klauke may void the FCC authorization to operate this equipment. General WORK SERVICE DON´T DO...
Seite 9
EK 60/22CFM Wann/When/Quand/Quando/ Warum/Why/Pourqoui/Porquê/ cuándo/Wanneer/Когда/это ¿por qué?/Waarom/Причина/ происходит/Kiedy/quando Dlaczego/Perché nach Arbeitsvorgang after working cycle après opération de travail Después del proceso de trabajo após o processo de trabalho 20 sec na bedrijfscyclus после цикла опрессовки po zakończeniu pracy dopo il processo di lavoro...
Seite 10
EK 60/22CFM Kennzeichnung Verb. Pressbereich Press- Marking geeignet für material mm² form Pres- suitable for Connection Crimping Crimping außen sprofil material range mm² mold outside Profile Rohrkabelschuhe und Verbinder - Cu (gelb chromatiert, Pressbreite 5 mm) Copper tubular cable lugs and connectors - Cu (chrome plated, crimping width 5 mm) Rohrkabelschuhe und Verbinder „Normalausführung“,...
Seite 11
EK 60/22CFM Kennzeichnung Verb. Pressbereich Press- Marking geeignet für material mm² form Pres- suitable for Connection Crimping Crimping außen sprofil material range mm² mold outside Profile Klemmen und Schraubverbinder (gelb chromatiert, Pressbreite 5 mm) Clamps and screw connectors (chrome plated, crimping width 5 mm)
Seite 12
EK 60/22CFM Crimp Chart 22 tool series Hex crimps Klauke R-series Copper connector type Ring type Angle type 90° Angle type 45° Copper lugs R-series 3Rxx - 12Rxx 43Rxx - 52Rxx 43Rxx45 - 52Rxx45 (Class 2 & 5) Copper slices R-series (Class 2 &...
Seite 13
Dipl.-Ing. Joh.-Christoph Schütz, CE-Beauftragter EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 i henhold til bestem- melseme i direktiverne 2006/42/EØF, 2014/30/EU, 2011/65/EU Gustav Klauke GmbH • Auf dem Knapp 46 • D-42855 Remscheid Telefon ++49 +2191-907-0 • Telefax ++49 +2191-907-141 • www.klauke.com...
Seite 14
EN 60950-1, EN 301489-1, EN 301489-17, EN 300328 V2.1.1, EN 62479 i Dipl.-Ing. Joh.-Christoph Schütz, CE-Beauftragter henhold til bestemmelseme i direktiverne 2014/53/EU, 2011/65/EU Gustav Klauke GmbH • Auf dem Knapp 46 • D-42855 Remscheid Telefon ++49 +2191-907-0 • Telefax ++49 +2191-907-141 • www.klauke.com...
