5.2.2 Measuring interval
For the measuring interval, various intervals between 1 s and 12 h are possible.
5.2.3 Start condition
The data logger can either be started manually by a keystroke or automatically at a certain date
which is set in this menu.
5.2.4 Stop condition
There are three different options for stopping the data logger. You can either stop the data logger
manually by a keystroke, at a certain date or after a set time interval.
5.2.5 Delete data / Delete all
Via these two menu items, either individual data records or all saved data records can be deleted
at a time.
5.3 Memory
When manual memory is enabled, individual measurements can be saved to the internal memory
for later viewing.
5.3.1 Select folder
Here, the current folder for the memory can be selected. A total of 99 folders for 50 individual
measurements each is available.
5.3.2 Display data
With the help of these functions, the measurements saved in the currently selected folder can be
viewed again.
5.3.3 Delete data / Delete folder / Delete all
These menu items are used to delete an individual measurement or all measurements in the
current folder or all measurements in all folders.
5.4 Route measurement (PCE-VT 3900 only)
This menu is used to start saved routes and to display or delete readings belonging to the routes.
5.4.1 Start route
The routes must be configured using the PC software and transferred to the meter. After the
routes have been transferred to the device, a single route can be selected and started with this
menu item.
