13. TECHNISCHE DATEN
eCOMPACT4BT
Input Sensitivity and Input Impedance
Frequency Response
Input Selector
Aux Input (on INPUT 1)
Gain control
Tone control
THD+N
Signal Noise Ratio
CMRR
MICRO 2-4 High Pass Filter
Outputs Level
Output VU-METER
STEREO / MONO
ALT OUT
LINE, LINE A, LINE B
MICRO (BAL)
AUX INPUT IN1
BT INPUT
LINE, LINE A, LINE B
MICRO (BAL)
AUX INPUT IN1
BT INPUT
INPUT 1
INPUT 2
INPUT 3
INPUT 4 (TALKOVER)
GAIN
BASS
MID
TREBLE
LINE
MICRO
AUX
BT INPUT
LINE
MICRO
AUX INPUT IN1
BT INPUT
BAL INPUTS
MAIN OUT
SUB OUT
ALT OUT
HEADPHONES
0dBV/50k
-35dBV/>1k
-10dBV/316Ω
-10dBVFS
10Hz÷30kHz, -1dB
10Hz÷30kHz, -1dB
10Hz÷30kHz, -1dB
10Hz÷30kHz, -1dB
BT, LINE + AUX
LINE A, MICRO, LINE B
LINE A, MICRO, LINE B
LINE, MIC
Connected to INPUT1 LINE
± 15dB
100Hz, ± 15dB
2kHz, ± 15dB
10kHz, ± 15dB
<0,03%
<0,06%
<0,03%
<0,05%
>100dB
>90dB
>100dB
>100dB
>75dB @ 1kHz
100Hz, -3dB – 2nd order
0dBV
0dBV
0dBV
200mW
+6dB to -40dB, MAIN OUT or ALT OUT selectable
Functional only over MAIN OUT, SUB OUT and
HEADPHONES
Selectable by ALT OUT SEND buttons in each
CHANNEL
