Specifications
2.1
Technical specifications
Specifications of the meter PCE-TG 300
Specification
Measurement range
Accuracy
Resolution
Measurable materials
Operating modes
Calibration
View mode
Units
Data transfer
Memory
Operating time
Power supply
Display
Operating
temperature
Storage temperature
Relative humidity
Dimensions
Weight
Description
P-E: pulse-echo mode 0.65 ~ 600 mm (steel)
E-E: echo-echo mode 2.50 ~ 60 mm
±0.04 mm (<10 mm); ±0.4 % H [mm] (>10 mm); H refers to the material
thickness of the workpiece
0.1 mm / 0.01 mm / 0.001 mm (adjustable)
Metals, plastics, ceramics, epoxy resin, glass and any material with a
homogeneous structure
Pulse-echo mode (fault and cavity recognition)
echo-echo mode (hiding coating thicknesses, e. g. lacquers)
Sound velocity calibration, zero point calibration, two-point calibration
Normal mode, scan mode, difference mode
mm / inch
Printing via Bluetooth
Data transfer via USB 2.0
Non-volatile memory with 100 data sets of 100 data records each
Continuous operation 100 h
Automatic Standby mode (adjustable)
Automatic Power Off mode (adjustable)
4 x AA
battery (DC) 1.5 V
320 x 240 TFT LCD colour display with adjustable brightness
0 ...+50 °C
-20 ...+70 °C
≤80 % RH, non-condensing
185 mm x 97 mm x 40 mm
375 g
© PCE Instruments
17
