1
7
50 1000
45 900
40 800
35 700
3
30 600
25 500
20 400
15 300
10 200
5 100
5
ON
3a
When the device is turned on, the display will show
the ambient temperature for 3 seconds.
3b OFF
3 sec
10
GB
1 Wood groups A / B,
6
moisture in %
2
2 Index mode (Building materials)
3 Bar graph display for
wood groups A/B
4 Bar graph display
4
for index mode
5 Numeric measurement value
in % / Index value
6 Low battery charge
7 Display arrow: Value out
of range indicator
8 On/Off switch, Switch-over
to wood groups A and B,
index mode
8
The device switches itself off
automatically after 3 minutes to
save battery power. If the device
has switched itself off, use the
On/Off switch again to switch it
on again.
3 sec
50
45
40
35
30
25
20
15
10
5
DampFinder Compact
