，SETUP – LED PIXEL – LED
With the UP/DOWN-buttons you can chose the desired LED-type. With ENTER-button the highlighted value
will be saved and the menu will be left.
With ESC-button you can leave the menu without saving any changes.
，SETUP – LED PIXEL – LED
The controller has two digital outputs to control Digital Strips. In this menu you can set the amount of LEDs
you have connected or you want to control at each digital output.
With the UP/DOWN-buttons you choose the output. After pressing ENTER-button you have the possibility to
change the amount of LEDs. You can do this by pressing or holding the UP/DOWN-button.
With ESC-button you will leave the menu. The changed values will be saved.
，SETUP – LED PIXEL –
In RESOLUTION-menu you can chose how many LEDs are one pixel. You can enter values between 1 and
100.
MBN GmbH, Balthasar-Schaller-Str. 3,
TYPE，
COUNT，
RESOLUTION，
